Baxi 800 Heat

Baxi 800 Heat Only Boiler

Heat Only Boilers

Baxi 800 Heat

The Baxi 800 Heat includes a compact Adey MagnaClean Micro2 system filter to protect the boiler and heating system.


This boiler can be installed on open vent or sealed systems and has an optional in-case rear flue for a neater installation.

Wonga. Dough. Moolah. Bread. Call it what you want, we call it cash!

From 1st September, Baxi Works members will receive £300 for every three boilers they install and register from the 600 and 800 ranges. This promotion is uncapped, meaning unlimited dosh!

boiler-cashbach-hero-wording

Features and Benefits

Multiple outputs

Available in outputs of 16, 19, 25 and 30kW

Flexible

Top central or optional in-case rear flue giving flexibility to site

Lightweight

Only 17.4kg installer lift weight (30kW is 19.5kg) for easy installation

Secure

Easy-fit wall mounting bracket featuring a positive fix and audible lock, so you know it’s secure

Time-saving

No pump overrun or permanent live required, saving time and money during installation
Show More
Show Less

Product Literature

User Guides

User Guides

Specification Guides

Specification Guides

Product Documentation

No documentation available.

Data Sheets

Sheet Title

Energy Labels

Energy Labels

CAD

CAD

Solutions Brochure

Solutions Brochure

Baxi Heat Only Boiler Dimensions

Dimensions

A: Boiler Width = 370mm

B: Boiler Height = 625mm

C: Boiler Depth = 270mm

D: Side Clearance = 5mm

E: Upper Clearance = 190mm*, 35mm* if used rear flue

F: Lower Clearance = 120mm*, 35mm* in 300m deep wall cupboard

G: Front Clearance= 5mm* in operation (500mm for servicing)

Technical Specification

Product Model16192530
Product Code7749866789883277498687749869
Controls and accessories
Operating mode selector switch with reset (Yes/No)YesYesYesYes
User adjustable CH temperature (Range - e.g. 45° to 82°)YesYesYesYes
LED temp/status/fault diagnosis display (Yes/No)YesYesYesYes
Baxi twin channel wired programmer -7212443OptionalOptionalOptionalOptional
Baxi room thermostat -720971601OptionalOptionalOptionalOptional
Gas
Boiler Plus ErP (%)939393
SAP 2009 annual efficiency (PCDB/SEDBUK) %89.289.289.189.1
NOx class6666
ErP Product Information
NOx (mg/kWh)20252424
Sound Power Level, Indoors (LWA dB)39414549
Space Heating Efficiency ClassAAAA
Heat Input CH - kW max gross (QnHs)18.3221.7528.6234.35
Heat Input CH - kW min gross (QnHs)8.598.598.598.59
Heat Output CH (non condensing) kW (Pn)16192530
Heat Output CH (non condensing) kW (Pn)7.56.47.57.5
Gas supply connection (mm)22222222
Inlet supply pressure (natural gas) mbar20202020
Maximum gas rate (m3/hr)1.752.072.733.27
Mechanical and hydraulic
Compartment ventilation required (Yes/No)NoNoNoNo
Flow / return pipe size (mm)22222222
Condensate discharge pipe size (mm)21.521.521.521.5
Electrical
Electrical supply (Volts/Hz)230V/50Hz230V/ 50Hz230V/50Hz230V/50Hz
Permanent live required (Yes/No)NoNoNoNo
Switched live (Yes/No)YesYesYesYes
Electrical power cable fitted as standard (1m of 3 core)YesYesYesYes
Power consumption (Watts)20233344
External fuse rating (Amps)3333
Internal fuse rating1.6T1.6T1.6T1.6T
Boiler IP rating (electrical protection) -Approval categoryIPX4DIPX4DIPX4DIPX4D
Pump overrun (Yes/No)NoNoNoNo
Concentric flue system
Standard telescopic concentric flue (Length in mm)315-500315-500315-500315-500
Horizontal and Vertical concentric (60/100 mm) - Max equivalent length (m)6666
Horizontal and Vertical concentric (60/100 mm) - Reduction per 135° bend (m)0.50.50.50.5
Horizontal and Vertical concentric (60/100 mm) - Reduction per 93° bend (m)1111
Weights
Installer lift weight (boiler) Max (kg)17.417.417.419.5
Gross packaged boiler weight (kg)21.319.421.321.3
